Technical Information

This part of the help manual is written explicitly for encouraging anyone interested in the topic to write his/her own system, using whatever he/she wants from these ideas. It is also meant to provide a general overview of how Divinum Officium and Sancta Missa are internally structured.
Following the provisions of the MIT License, and in accordance with the wishes of the late Laszlo Kiss, the only restriction is that we at The Divinum Officium Project have no legal responsibility for any errata, and the ideas cannot be copyrighted, limiting our rights or the access of others to the same ideas.

Top

The databases are files, which contain the text of the Breviary. For easier understanding and handling, they are organized into folders. All files use UTF-8 encoding. If adding files, please be aware of this, as it can and will effect the appearance of text.

The top level folders are folders for the languages (Latin, English, French, etc.). The basic rule is that if a file is missing for a specific (modern) language, the program automatically selects the language text from the English. (Exception: Hyphenated language folders (e.g., Polski-Newer) first select the un-hyphenated folder of that language first.

Each language folder contains the same set of subfolders, which represents the parts of the printed breviary volumes: Psalterium, Tempora, Sancti, Commune. For technical reasons, there are separate folders for the psalms and for the Martyrologium. The Latin folder "psalms" contains unaccented psalms, while "psalms1" contains the accented psalms, and "PiusXII" contains the Pius XII psalter. Folders marked "M" are used to display the Monastic version of the Office. Whenever separate files in the "M"-folders are unnecssary, the script defaults to that same folder without "M".

The style and punctuation used within the text is that of the 1962 liturgical books (i.e. natalicio is preferred to natalitio, abicere to abjicere, etc.), with the exception that one space is used between sentences, and no space is placed before a colon or other punctuation. In accordance with the principles sent to the typographers of the 1960 editiones typicae, the letter J in the 1960 rubrics is transformed to the letter I. (Sacrae Congregatio Rituum, "Ordinationes ad librorum liturgicorum editores", 26.VI.1960) The code is capable of automatically making certain typographical and rubrical changes to account for these and other variations in the 1960 rubrics.

The files itself usually are converted into hash elements, e.g. [Ant Matutinum], [Capitulum Nona], etc.

The key is enclosed within square brackets [ ... ] which is a separate line followed by the body of the element. For instance, [Ant 2] refers to the Benedictus antiphon at Lauds, while [Lectio93] normally refers to the 9th (hagiographical) reading of a commemorated saint (pre-1960), which became the 3rd reading at Matins on 3rd class feasts under 1960 rubrics.

These elements are read and composed by the code.

The folder and files can be viewed within the GitHub repository, which shows the files in the following folders in the directory ~/, ~/horas/ and, subsequently, ~/horas/Latin/ (or any modern language):

• Tabulae contains the transfer tables and is found in the top-level folder ~/ only.
  File data.txt provides map information for officium versions used in files in below directories:
  • Kalendaria sanctoral kalendar files.
    • Lines starting with * or #- signs are comments.
    • Other lines are devided in multiple parts by the = char. Within the second section, multiple offices can be assigned to a single day, the latter ones by way of commemoration. These are divided by the ~ char.

    • Please note that everything after the second = is for information only and not used by the code itself.
    Meaning is explained in example from file 1888.txt :
    01-11=01-11~01-11cc=Sexta die infra Octavam Epiphaniae=2=S. Hygini Papæ et Martyris=1=
    On January 11, there is the office contained in file 01-11 (the 6th day of the octave of the Epiphany) with a commemoration of S. Hyginus Pope and Martyr contained in the seperate file 01-11cc.
  • Tempora perpetually-transfers of the Tempora (Divino Afflatu is used as base).
  • Transfer transfers based on Easter date.
    • Lines starts with '#-' signs are comments.
    • Other lines are divided in three parts: before '=' char, between '=' and ';;', and after ';;'.
    Meaning is shown in examples from files a.txt and 402.txt respectively:


    01-11=01-10~01-11cc;;1570 1888 1906
01-12=01-11;;1570 1888 1906
    On January 11th, in all years with Dominical letter 'A' and under the Tridentine rubrics only, the office is of the 5th day of the octave (transferred from Jan. 10) but still with the commemoration of S. Hyginus.
    On January 12th, in the same years and under the same rubrics, the office is of the 6th day of the octave (transferred from Jan. 11) but without the aforementioned commemoration.

    03-20=03-19t;;1570
03-20=03-19;;1888 1960 DA M Newcal
    In every year where Easter Sunday is on April 2nd, on the day March 20th there is Solemnity of St. Joseph (March 19th) for versions (1888, 1960 etc.; used short versions names from mentioned above file data.txt). For 1570, a different database file is used while in 1906, St. Joseph outranked the Sunday (temporarily) and does not get transferred.

    dirge1=01-23 02-03 02-20;;1570
    lists days where Officium Defunctorum is read after Vespera and Laudes. (dirge1 is for January and February, dirge2 for remaining months).

    Hy05-18=1;;DA
    marks days where major hymns should be altered according rule XX.3. (1 means merge hymns in Matutinum, 2 - shift hymns)
  • Stransfer as above but for transfers of Matutinums readings.
• The Ordinarium folder is the collection of the scripts structuring the canonical hours. It is found directly in the folder ~/horas/. Each hour is represented by one file with the exception of Matins where a second file for the sole use on Epiphany day is to be found there. These files are not converted into hash.
  A line starting with # organizes the content (skeleton) and is expanded by the special.pl program file. For lines starting with $ and & see [Special characters].
• Psalterium folder holds the information usually printed in the Ordinarium and Psalterium sections of the Breviarium Romanum. Prayers.txt contains the common prayers. The rest contains the Benedictions, Doxologies, specific forms of the Invitatory, seasonal parts for Matins (Matutinum special), Lauds & Vespers (Major special); Minor hours (Minor special); antiphons and psalm sets (Psalmi Major|Matutinum|Minor), Marian antiphons, and special seasonal parts for Prime (Prima special).
• Psalms folder holds the 150 psalms, and the canticles for
  • 210-216 = Laudes 1;
  • 220-226 = Laudes 2;
  • 231-234 = New Testament canticles and the Quicumque
  The verses are numbered by chapter:verse numbers, and anything in parentheses is printed in small red font.
• The Tempora folder holds the offices from the Proprium de Tempore. Each office has exactly one file, and each is a hash collection. The naming convention is:

  Season name w-d

  where w is the week of the season, and d is the day of week. (Example: Pent04-2 represents Tuesday of the 4th week after Pentecost. Similarly, 085-0 represents Sunday of the 5th week of August.)
• Sancti is the same collection of offices as found in the Proprium Sanctorum. The naming convention is:

  mm-nn

  where mm is the month, nn is the day. (Example: 07-26 represents July 26, Feast of St. Anne.) For practical reasons, unlike in the Missale Romanum or Breviarium Romanum, the Christmastide offices are split and the "Sanctoral parts" only are placed within the Sancti folder. Files are marked with certain letters for their usage within certain rubrical structures:


  • t = 1570 rubrics;
  • o = 1888 / 1906 rubrics;
  • r = 1960 rubrics;
  • da = Divino Afflatu rubrics;
  • n = 1960 rubrics with new calendar additions;
  • p = Paschaltide;
  • q (appended as suffix to one of the previous) = file to be used during Lent;
  • t (appended as suffix to one of the previous) = file to be used when an office is to be transferred.
  • cc = Simplex feasts perpetually impeded (hence only commemorated, and adressed accordingly in the Kalendarium and Transfer files; see below)

  Each feast is assigned a number for ranking purposes, which can be augmented by a decimal to slightly increase or decrease the rank. To ensure consistency across the database, ranking information is solely extracted from the Latin language files (with the exception of translations of an offices name); everything after the first ;; mark in the [Rank] hash of other languages is ignored. To accomodated the various rubrical structures and their slightly different rules for Occurrence, Concurrence, and Commemorations, apart from very few exceptions, the following ranks are used:

  General Rank	Duplex		Semiduplex		Simplex		Rank
  	Festum	Dies 8va	Dominicæ	Dies infra 8vam	Vigiliæ	Feriæ
  I. classis	Duplex I. cl. (max. sollem.)			I. ordinis			7.0	Excludes all commemorations
  			I. classis		Pentecostes (I. classis)	Feria privilegiata	6.9
  	Duplex I. classis				Nativitatis (I. classis)		6.5
  		II. ordinis					6.3
  	Patronus Eccl.						6.2
  			II. classis (Trid. pre-1900: "IS. ordinis")	Epiphaniæ (Trid.: "IS. ordinis")			6.1
  	Duplex I. classis (in Adventu & Quadr.)						6.0
  II. classis			II. classis (1906 & Divino)	II. ordinis (Divino)			5.6
  	Duplex II. classis						5.0
  Majus		Corpus Christi (Trid.: "IIS. ordinis")	per annum (Divino)		Epiphaniæ (Divino: II. classis)	Feria privilegiata II. ordinis (Monastic juxta Divino)	4.9
  		III. ordinis					4.2	This and above always commemorated.
  		communis (Divino)					4.1
  	Duplex majus						4.0
  minus						Feria III. classis in Quadragesimæ (1960)	3.9	Exact rank always commemorated.
  		communis (Trid.)					3.1
  	Duplex minus						3.0
  Semiduplex							2.99	Used dynamically at Vespers for Dominicæ majores (Trid.); always commemorated.
  			Dominica minor (Trid.)	Corpus Christi (Trid.: "IIS. ordinis")	Epiphaniæ (Trid.: tamquam Dominica)		2.9
  					Vigilia in Adventu (ad Missam)		2.5	Used only for Missa when Office is of the Feria but Mass of the Vigil.
  	Semiduplex						2.2
  				Immaculatæ Conceptionis (quia in Adventu)			2.19
  				III. ordinis		Feria major	2.1	Exact rank always commemorated.
  				communis			2.0
  Simplex					Vigilia communis		1.5
  		Simplex (Divino)					1.4
  	S. Maria in Sabbato						1.3
  	Simplex						1.2
  	Commemoratio					Feria minor	1.0

• Commune is the collection for Commune Sanctorum. The name of the office is under the first key: Name. See below for examples.
• Martyrologium contains the files named as mm-nn (in the same way as the Sancti folder) for the Martyrologium. Please note that the Martyrology at Prime is anticipated for the subsequent day. In the Latin text, there exist different folders containing the Martyrology corresponding to the different rubrical structures. For instance, the folder ~/Latin/Martyrologium1960 represents the Martyrology as used in the 1960 rubrics, while ~/Latin/Martyrologium1955R will display that from the 1955 rubrics. Please see credits for the sources.

Top

• officium.pl Starts the Divinum Officium Desktop program. Composes the main page and also calls upon other scripts.
• Pofficium.pl Starts the Divinum Officium Mobile program. Composes the main page and also calls upon other scripts.

Main Perl Scripts
• horas.pl Interprets the special characters and prints out the Officium for the selected hour.
• special.pl Fills up the skeleton chapters with the actual content from the databases.
• horascommon.pl The file selects the current date, and the office for any given date, and provides rules for precedence.

Auxiliary Perl Scripts
• dialogcommon.pl Interprets the defaults and setup.
• webdia.pl Helper set to generate the dialog table, special html parts of the office tables, and also reads/writes cookies.
• setup.pl Generates the dialog box to set the parameters for web versions.
• popup.pl Generates a popup window if requested by the horas page.
• kalendar.pl Displays the Kalendar and makes it possibile to select a specific date. Uses horascomon.pl and horas.pl script sets.
• edit.pl. Shows the datebase program and other files for the web versions. Uses horascommon.pl.

.txt Files
• Files (i.e. those found in ~/web/www/horas) is the collection of the internal databases for the web versions, broken down by language.

Top

• # in the files of the Ordinarium folder represent a chapter label, e.g. Incipit, Psalms, etc. The Special.pl program interprets and expands or limits primarily these lines. Therefore, they represent the basic structure of the particular Hour.
• [ name ] in a separate line is the key for a hash element, as mentioned earlier.
• $ dollar sign as the first character of a line, followed by a name, represent a prayer found in Psalterium/Prayers file. These are the candidates for Popup if psalmi option is called. Some invoke an internal subroutine.
• & sign calls an internal subroutine. If the subroutine name starts with capital letter that is listed only in all mode, if it starts with small letter, psalmi option will expand it.
• @ sign cross-references back to a hash element in another (or the same) file. For instance, @Sancti/12-25:Capitulum Laudes will refer to the Lauds capitulum on Christmas Day. @:Ant 1 will refer to the 1st Vespers Magnificat antiphon within the same file.
• ! An exclamation point (at the beginning of a line) will print the line with red font.
• v. prints the following first letter in large red font.
• r. prints the following first letter as regular red font.
• R.br R. V. * Ant. Benedictio These starting words are printed in regular red font.
• double end of line represents a cell end, the printout will set a border separator.
• _ underscore in itself in a line represents an empty line without a border separator.
• ~ tilde at the end of the line represents contraction of a line of text.
• ( text ) in psalm folder will print the enclosed text in small red font.
• Digits or digits:digits at the beginning of the line in psalms and readings are interpreted as verse numbers, and are printed in red.
• Common Offices (Cn) refer to the Commune Sanctorum:

C1 : Common of Apostle	C1a : Common of Evangelists C1v : Vigil of Apostle
C2 : Common of One Martyr	C3 : Common of Several Martyrs
C4 : Common of Confessor, Bishop or Pope (with variations)	C4a : Common for a Bishop-Doctor of the Church
C5 : Common of Confessor not Bishop	C5a : Common for Doctor of the Church (not a bishop)
C6 : Common of One Virgin Martyr	C6a : Common of Several Virgins C6b : Common of a Virgin
C7 : Common of a Holy Woman Martyr	C7a : Common of Holy Women C7b : Common of Several Holy Women Martyrs
C8 : Common of the Dedication of a Church	C9 : Office of the Dead
C10 : Office of the Blessed Virgin for Saturday	C11 : Common for the Blessed Virgin Mary
C12 : Little Office of the Blessed Virgin Mary
other : reference to Proper office	p added to the name : Eastertime Office

Top

Many of the files in Tempora or Sancti folders have an entry: Rule. There are the exceptions from those rules built into the Ordinarium and the Psalterium and represented by the files in those folders. A usual [Rule] item looks like:

[Rule]
ex C4;
Psalmi Dominica
Antiphones horas
9 lectiones


Each rule is a separate line and exact spelling is required, except for capitalization.

Rule item	Description	Example	Use case
ex file	everything that is not in the Proprium is taken from the named file from the Commune or from the file in the Tempora or Sancti folder	ex C2; ex Pasc0-0; ex Sancti/05-08
vide file	like above, but only the Matins lections and the Lauds & Vespers antiphons, versum, & oratio are taken from the named file.
mtv	Changing the third verse in Iste confessor hymn	vide C4a;mtv	Sancti/01-14
Psalmi Dominica	The Sunday psalm set is used, except if the psalm is explicitly indicated as being proper in the Proprium file.		Sancti/01-01
Feria Te Deum	Te Deum is sung at the end of Matins even on a Feria.		Sancti/01-02
Festum Domini	Under Rubrics 1960, such a feast still trumps any minor Sunday.		Sancti/01-06
Antiphonas horas	Laudes antiphons are used for the minor hours: Ant 1 => Prima Ant 2 => Tertia Ant 3 => Sexta Ant 5 => Nona		Sancti/01-06
9 lectiones 12 lectiones	Matins with 9 (or 12) lessons, i.e., 3 nocturns.		Sancti/01-06 SanctiM/01-06
Doxology=season	Doxology of Hymns changes according to the season.	Doxology=Epi	Sancti/01-06
Psalm5 Vespera=ddd	The last psalm in (2nd) Vespers is the named one.	Psalm5 Vespera=116 Psalm5 Vespera3=113	Sancti/01-06
omit group list	Skip the named item.	Omit ad Matutinum Incipit Invitatorium Hymnus	Sancti/01-06
limit group list	Special (hard coded) rules for the named items (on all Souls and Triduum Sacrum).
Minores sine antiphona	Minor hours are prayed without an antiphon (e.g., Triduum).
Lectio1 tempora Lectio1 OctNat	Replacing 1st Nocturn readings according to the rules in the Octaves of Epiphany and Nativity.		Sancti/01-07 Sancti/12-31
scriptura1960	Under Rubrics 1960, 1st Nocturn lessons are taken from occuring scripture.		Sancti/08-29
No ordinal vespera	Prevents a feast to win or be commemorated at second/first vespers	no secunda vespera	Sancti/01-12
(OC)Papa(e))(CMD)=name	Provides the name for a C(onfessor), M(artyr), or D(octor) Pope(s) in the O(ffice) or C(ommemorated)	OPapaM=Hygínum; CPapaC=Marcum;	Sancti/01-11cc Sancti/10-07
Sub unica concl	Joining Prayers under one conclusio (esp. Peter + Paul)		Sancti/01-18
in d Nocturno Lectiones ex Commune in dd loco	Taking lessons from the respective place in the Commons.	in 3 Nocturno Lectiones ex Commune in 3 loco;	Sancti/02-05
Una antiphona	Major hours are prayed under one antiphon (e.g., Paschal tide).
1 nocturn	Matins of one nocturn only (e.g., Paschal octave).
3 lectiones	Ferial style Matins under Monastic rules (e.g., dies infra Octavam).
Capitulum Versum 2 [hour spec]	Capitulum is substituted with the [Versum 2] item from the Propria. This occurs at all hours other than Compline if hour spec is omitted, at Lauds and Vespers if hour spec is ad Laudes et Vesperas, and at Lauds only if hour spec is ad Laudes tantum.		Tempora/Pasc0-0

Top

The database files contain various types of conditional statements in parentheses which enables the scripts to access the hash elements for various rubrical structures and for various dynamic cases such as what Feria a day occurs on. The general format for such conditionals is as follows:

stopword	condition	scope descriptor	instruction
(optional) si deinde vero sed atque attamen	(optional subject) predicate [& et/aut...] (tempore) nativitias rubrica tridentina feria 3 aut feria 6 commune C11 missa tertia die Sabbato Sancto (etc.)	(optional) loco hujus versus loco horum versuum hic versus hi versus	(optional) dicitur (semper) dicuntur (semper) omittitur omittuntur

Each conditional can have forward and backward scope. The stopwords si and deinde have forward scope. The other stopwords have implicit backward scope unless combined with dicitur semper or dicuntur semper. For nesting purposes, the stopwords have increasing "weight" in the given order.

The instructions omittitur and omittuntur force backwards scope and prevent any forward scope. The singular goes back until the last line break, which in the DO database can also be given by a "joiner line", i.e., a single underscore _. The plural goes back as far as possible unless stopped explictly by a forward scoped statement.

The instructions dicitur and dicuntur force forward scope but do allow backward scope unless followed by semper. The extent of the scope depends on the scope descriptor:

• without scope descriptor: single line backscope depending on stopword (see above); single line forward scope for singular and multi paragraph for plural
• loco hujus versus dicitur/dicuntur: single paragraph backscope with single paragraph forward scope
• loco horum versuum dicitur: multi paragraph backscope with single paragraph forwards scope
• loco horum versuum dicuntur: multi paragraph backscope with multi paragraph forwards scope

To fully embrace the power of conditionals, please have a look at this (indented) example from the beginning of Ordinarium/Completorium.txt

#Incipit
$benedictio Completorium
$Amen

#Lectio brevis

$Adjutorium nostrum
(rubrica 196) $examen
(atque dicuntur semper)
	$Pater noster
	(rubrica cisterciensis) $Ave Maria
		(deinde dicitur)
			$Confiteor
			$Misereatur
		(sed rubrica cisterciensis omittitur)
		(deinde dicitur)
			$Indulgentiam
		(sed rubrica Ordo Praedicatorum aut rubrica cisterciensis omittitur)
	$Converte nos
(atque rubrica altovadensis omittuntur)

(rubrica cisterciensis) $clara voce
$Deus in adjutorium
(deinde dicitur)
	&Alleluia
(sed rubrica cisterciensis omittitur)
